Syringe scale printing machine


Main technical parameters

1. These sizes of syringe could be printed: 10ml and other sizes;

2. Capacity: not less than 120 pcs/min for 10ml syringe.

3. Dimension: 4500 × 1500 × 2000mm.

4. Temperature: the temperature inside the case is room temperature, max. 10 centigrade degrees, automatically adjust the constant temperature, case surface temperature ≤40 centigrade degrees.

5. Staff: 1 staff for one machine.

6. Material feeding: automatically material feeding, centrifugally distribute the materials.

7. There is high-pressure spray gun for silicon oil spraying. The silicon oil atomizing could be adjusted inside the high-pressure tin and under the range   of air valve.

8. Lifetime: not less than 8 years ( not including the components ), periodical maintenance during the constant working could ensure the machine’s lifetime.

9. Machine power: 3KW, input power: 220V, 50Hz.

10. Weight: 500KG.

11. Air pressure: 0.2 – 0.4 Mpa.
